Ground distribution circuit for Mitsubishi Eclipse Cross I (2017-2022)
Ground distribution circuit (2 of 2)
A-109
BLK WIRE
C-129
C-240
CONDENSER FAN MOTOR, ENGINE COMPARTMENT RELAY BOX
DASH GROUNDING J/C (C-202)
EPS-ECU
FCM ON/OFF SWITCH, HUD, COLCKSPRING, MULTI-VISION DISPLAY, ETACS-ECU,
HAZARD WARNING LIGHT SWITCH, TELEMATICS CONTROL UNIT (TCU)
J/C 4 (C-104)
J/C 9 (C-135)
KEY INTERLOCK SOLENOID, LDW SWITCH, COMBINATION METER, ENGINE SWITCH,
TOUCHPAD CONTROLLER, SRS-ECU,
