Wiring diagram engine performance 1.5l turbo for Mitsubishi Eclipse Cross I (2017-2022)

A-110 A-112 B-11 B-117 BLK WIRE BLU WIRE BRN WIRE CIPN COMBINATION METER COMPUTER DATA LINES SYSTEM CPEX CRANKSHAFT POSITION SENSOR DGND DI+1 DI+2 DI-1 DI-2 DI-3 ENGINE COMPARTMENT RELAY BOX ENGINE CONTROL MODULE EXHAUST CAMSHAFT POSITION SENSOR FUSE 17 FUSE 28 FUSE 29 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSIBLE LINK 39 FUSIBLE LINK BOX GRN WIRE GRY WIRE HFP- HIGH PRESSURE INJECTOR 3 HOT AT ALL TIMES INLET CAMSHAFT POSITION SENSOR LCD LEFL LHFL LINEAR AIR-FUEL RATIO SENSOR LPFL LT BLU WIRE LT GRN WIRE MALFUNCTION IND (SERVICE ENGINE SOON OR CHECK ENGINE LIGHT) MFI RELAY NCA WIRE OCVE OCVI OHRL PNK WIRE PURG RED WIRE THROTTLE ACTUATOR CONTROL MOTOR RELAY VIO WIRE WGMB WGMG WHT WIRE YEL WIRE

A-112 B-11 B-117 BLK WIRE BLU WIRE BRN WIRE C/RL DI+3 DI+4 DI-4 ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE OIL PRESSURE SWITCH EVAPORATIVE EMISSION PURGE SOLENOID EXHAUST ENGINE OIL CONTROL VALVE GRN WIRE GRY WIRE HFPG HFPS HIGH PRESSURE FUEL PUMP HIGH PRESSURE INJECTOR 1 HIGH PRESSURE INJECTOR 2 INLET ENGINE OIL CONTROL VALVE K/SE KNOCK SENSOR KS + LT BLU WIRE LT GRN WIRE MAIN MAP MAPE OPSW ORLE P/VT PNK WIRE RED WIRE SGT SUB + THROTTLE ACTUATOR CONTROL MOTOR THROTTLE BODY ASSEMBLY THROTTLE POSITION SENSOR TPSE TPSM TPSS UATS UPS VIO WIRE WGPG WGPS WHT WIRE WTS (+) YEL WIRE

A-110 B-117 BLK WIRE BLU WIRE BRN WIRE C-402 C-403 C-409 C-411 C-414 C-417 C-418 CAN DRIVE CIRCUIT CNMH CNML COMPUTER DATA LINES SYSTEM ETACS-ECU FUEL LEVEL SENSOR (MAIN) FUEL PRESSURE SENSOR FUEL PUMP MODULE FUEL PUMP RELAY FUEL TANK TEMPERATURE SENSOR FUSE 10 FUSE 15 GRN WIRE GRY WIRE HIGH PRESSURE INJECTOR 4 HOT AT ALL TIMES IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 INSTRUMENT CLUSTER SYSTEM INTERFACE CIRCUIT LT BLU WIRE LT GRN WIRE MANIFOLD ABSOLUTE PRESSURE SENSOR NCA WIRE PLUG PNK WIRE RED WIRE SPARK TOP OF ENGINE) VIO WIRE WHT WIRE YEL WIRE

A-109 A-110 A-112 BLK WIRE BLU WIRE BOOST PRESSURE SENSOR BRN WIRE C-118 C-122 C-29 DASH GROUNDING J/C (C-202) ENGINE COOLANT TEMPERATURE SENSOR EVAPORATIVE EMISSION VENTILATION SOLENOID GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION SWITCH INJECTOR 1 INJECTOR 2 INJECTOR 3 INJECTOR 4 INTAKE AIR TEMPERATURE SENSOR J/C 4 (C-104) J/C 5 (C-208, C-209) KOS, OSS-ECU (W/ KEYLESS ENTRY) (RIGHT SIDE OF DASH) LOCK LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE SGND STO TRANSMISSION RANGE SWITCH VIO WIRE W/ KEYLESS ENTRY W/O KEYLESS ENTRY WHT WIRE YEL WIRE

A-110 A-112 AC/R ACCELERATOR PEDAL POSITION SENSOR AFS AFSE AIR CONDITIONING SYSTEM APE APSE APSM APSS ATS BACK BBPS BLK WIRE BLU WIRE BPSE BRAKE BOOSTER VACUUM SENSOR BRAKE MONITORING SWITCH BRK BRN WIRE C-29 C/R CNTS COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DIAG ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE SWITCH ETV- F/TM FMB FPR FPRE FRP FUEL TANK DIFFERENTIAL PRESSURE SENSOR GNDB GNDE GRN WIRE GRY WIRE IGN IHBT INTAKE AIR TEMPERATURE SENSOR-1 LNBS B-10 LT BLU WIRE LT GRN WIRE MAIN MASS AIRFLOW SENSOR MASS AIRFLOW SENSOR (ON ENGINE AIR INTAKE DUCT) NCA WIRE PNK WIRE REAR HEATED OXYGEN SENSOR RED WIRE RSB RSG RSH STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STHI STLO STOP LIGHT SWITCH SUB + SW+ THROTTLE ACTUATOR CONTROL MOTOR TURBOCHARGER WASTEGATE POSITION SENSOR VIO WIRE WGM- WHT WIRE YEL WIRE
