Mitsubishi Eclipse Cross I (2017-2022) shift indicator panel assembly selector lever assembly Wiring diagram
This page shows the only wiring diagram for the component.shift indicator panel assembly selector lever assembly, which is found in the car Mitsubishi Eclipse Cross I (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift indicator panel assembly selector lever assembly (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
C-147
C-243
D ILL
DASH GROUNDING J/C (C-202)
DOT ILL
ECALL, BCALL SWITCH
ECO MODE SWITCH
ELECTRIC PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER)
F-09
FLOOR CONSOLE SPOT LIGHT
FRONT HEATED SEAT SWITCH
GRN WIRE
GRY WIRE
ILL
INSTRUMENT PANEL SPOT LIGHT
J/C 4 (C-104)
LEFT REAR HEATED SEAT SWITCH
LT BLU WIRE
LT GRN WIRE
MULTI- INFORMATION DISPLAY SWITCH
N ILL
P ILL
PNK WIRE
PPL/GRN WIRE
PPL/YEL WIRE
R ILL
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT REAR HEATED SEAT SWITCH
S-AWC DRIVE MODE SELECTOR
SHIFT INDICATOR PANEL ASSEMBLY SELECTOR LEVER ASSEMBLY
STEERING HEATER SWITCH
TOUCHPAD CONTROLLER
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> SHIFT INDICATOR PANEL ASSEMBLY SELECTOR LEVER ASSEMBLY
