Mitsubishi Eclipse Cross I (2017-2022) screen switching down switch wiring diagram
This page shows the only wiring diagram for the component.screen switching down switch, which is found in the car Mitsubishi Eclipse Cross I (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
screen switching down switch wiring diagram (1 of 1)
15 C-132
ABS WARNING LIGHT IND
ASC OFF IND
ASC OPERATION IND
AUTOMATIC HIGH BEAM IND LIGHT
BLIND SPOT WARNING LIGHT IND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE AUTO HOLD IND LIGHT
BRAKE WARNING LIGHT IND
BRN WIRE
BSW SETTING REAR CROSS TRAFFIC ALERT MESSAGE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM DISPLAY
DASH GROUNDING J/C (C-202)
DRIVER'S SEAT BELT WARNING LIGHT IND
ECO DRIVE ASSIST DISPLAY,
ECO INDICATOR DISPLAY, ECO MODE INDICATOR DISPLAY, ECO SCORE DISPLAY
ELECTRIC PARKING BRAKE WARNING LIGHT IND
ELECTRIC POWER STEERING SYSTEM WARNING LIGHT IND
ENGINE MALFUNCTION IND (SERVICE ENGINE SOON OR CHECK ENGINE LAMP)
FORWARD COLLISION MITIGATION SYSTEM OFF IND LIGHT
FRONT FOG IND LIGHT
GRN WIRE
GRY WIRE
HAZARD-WARNING IND LIGHT
HIGH BEAM IND LIGHT
ILL
J/C 4 (C-104)
KEYLESS OPERATION SYSTEM WARNING DISPLAY
LCD
LCD ABS WARNING DISPLAY, ASC WARNING DISPLAY, BRAKE WARNING DISPLAY
LCD ADAPTIVE CRUISE CONTROL SYSTEM DISPLAY
LCD AUTOMATIC HIGH BEAM SYSTEM WARNING DISPLAY, LED HEADLIGHT WARNING DISPLAY
LCD BRAKE WARNING ELECTRIC PARKING BRAKE WARNING
LCD DRIVER'S SEAT BELT WARNING DISPLAY
LCD ELECTRIC POWER STEERING SYSTEM WARNING
LCD FORWARD COLLISION MITIGATION SYSTEM WARNING, LANE DEPARTURE WARNING DISPLAY
LCD GENERATOR MALFUNCTION LIGHT DISPLAY
LCD ONE-TOUCH START SYSTEM WARNING, DOOR AJAR WARNING DISPLAY
LCD S-AWC DRIVE MODE DISPLAY (AUTO/SNOW/GRAVEL), S-AWC OPERATION DISPLAY
LCD SRS WARNING DISPLAY
LCD THE SAME INFORMATION, WARNING AS HUD
LCD TPMS WARNING DISPLAY
LCD WASHER FLUID LEVEL WARNING DISPLAY
LED HEADLIGHT WARNING LIGHT
LEFT TURN SIGNAL IND LIGHT
LT BLU WIRE
LT GRN WIRE
MENU SWITCH
MULTI- INFORMATION DISPLAY SWITCH
PNK WIRE
POSITION LIGHT IND LIGHT
RED WIRE
RHEOSTAT
RIGHT TURN SIGNAL IND LIGHT
SCREEN SWITCHING DOWN SWITCH
SCREEN SWITCHING UP SWITCH
SOUND SYSTEMS
SPEEDOMETER
SRS WARNING IND
TACHOMETER
TONE ALARM
TPMS WARNING IND
VIO WIRE
WARNING SYSTEMS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> SCREEN SWITCHING DOWN SWITCH
