Mitsubishi Eclipse Cross I (2017-2022) s-awc operation display) Wiring diagram
This page shows the only wiring diagram for the component.s-awc operation display), which is found in the car Mitsubishi Eclipse Cross I (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram s-awc operation display) (1 of 1)
AWC-ECU
BLK WIRE
BRN WIRE
C-147
C-402
C-410
C-412
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D-18
DASH GROUNDING J/C (C-202)
ELECTRONIC CONTROL COUPLING SOLENOID
ETACS-ECU
FUSE 13
FUSE 15
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
J/C 9 (C-135)
LCD
NCA WIRE
OFF ON
PNK BATT WIRE
PNK CANH WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
S-AWC DRIVE MODE SELECTOR
S-AWC OPERATION DISPLAY)
SOL +
SW 1
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> S-AWC OPERATION DISPLAY)
