Mitsubishi Eclipse Cross I (2017-2022) remote controlled mirror switch Wiring diagrams
This page contains all the electrical diagrams for the component. remote controlled mirror switch, in which he is found in the car Mitsubishi Eclipse Cross I (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram remote controlled mirror switch (1 of 3)
BLK WIRE
BLU WIRE
C-128
C-241
C-403
C-414
CONTROL CIRCUIT
DOOR MIRROR FOLD RELAY
DOOR MIRROR UNFOLD RELAY
ETACS-ECU
F-09
FUSE 5
GRY WIRE
HOT AT ALL TIMES
J/C 3 (C-105)
LEFT DOOR MIRROR ASSEMBLY
LT GRN WIRE
MRR
NCA WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RETRACTOR SWITCH
RIGHT DOOR MIRROR ASSEMBLY
UNFOLD/FOLD MOTOR
W/O SIDE VIEW CAMERA W/ SIDE VIEW CAMERA
Go to component -> Fold-back mirrors circuit -> REMOTE CONTROLLED MIRROR SWITCH
Wiring diagram remote controlled mirror switch (2 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
C-147
C-243
D ILL
DASH GROUNDING J/C (C-202)
DOT ILL
ECALL, BCALL SWITCH
ECO MODE SWITCH
ELECTRIC PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER)
F-09
FLOOR CONSOLE SPOT LIGHT
FRONT HEATED SEAT SWITCH
GRN WIRE
GRY WIRE
ILL
INSTRUMENT PANEL SPOT LIGHT
J/C 4 (C-104)
LEFT REAR HEATED SEAT SWITCH
LT BLU WIRE
LT GRN WIRE
MULTI- INFORMATION DISPLAY SWITCH
N ILL
P ILL
PNK WIRE
PPL/GRN WIRE
PPL/YEL WIRE
R ILL
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT REAR HEATED SEAT SWITCH
S-AWC DRIVE MODE SELECTOR
SHIFT INDICATOR PANEL ASSEMBLY SELECTOR LEVER ASSEMBLY
STEERING HEATER SWITCH
TOUCHPAD CONTROLLER
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> REMOTE CONTROLLED MIRROR SWITCH
Wiring diagram remote controlled mirror switch (3 of 3)
BLIND SPOT WARNING LIGHT
BLK WIRE
BLU WIRE
BRN WIRE
C-128
C-241
CONTROL CIRCUIT
DEFOGGER SYSTEM
DOWN
F-09
FOLD-BACK MIRRORS CIRCUIT
GRN WIRE
GRY WIRE
HEATER
HORIZONTAL MOVEMENT MOTOR
ILL
LEFT
LEFT OFF
LT BLU WIRE
LT GRN WIRE
NAVIGATION SYSTEM
NCA WIRE
OPERATION SWITCH
PNK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/YEL WIRE
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RETRACTOR SWITCH
RIGHT
RIGHT DOOR MIRROR ASSEMBLY
RIGHT SIDE TURN SIGNAL LIGHT
RIGHT SIDE VIEW CAMERA
RIGHT/LEFT CHANGEOVER SWITCH
UNFOLD/FOLD MOTOR
VERTICAL MOVEMENT MOTOR
VIO WIRE
W/O SIDE VIEW CAMERA W/ SIDE VIEW CAMERA
WHT WIRE
Go to component -> Power mirrors circuit (2 of 2) -> REMOTE CONTROLLED MIRROR SWITCH
