Mitsubishi Eclipse Cross I (2017-2022) left electric parking brake actuator Wiring diagram
This page shows the only wiring diagram for the component.left electric parking brake actuator, which is found in the car Mitsubishi Eclipse Cross I (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left electric parking brake actuator (1 of 1)
+ECU
AUTO- HOLD
BLK WIRE
BLU WIRE
BRAKE AUTO HOLD LIGHT IND
BRAKE AUTO HOLD SWITCH
BRAKE WARNING LIGHT IND
BRN WIRE
C-151
C-208
C-209
C-227
C-29
C-402
CAN L
CANH C-226
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D-27
D-28
DASH GROUNDING J/C (C-202)
ELECTRIC PARKING BRAKE ECU
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE WARNING LIGHT IND
ENGINE COMPARTMENT RELAY BOX
ETACS-ECU
FUSE 15
FUSE 25
FUSIBLE LINK 1
FUSIBLE LINK 2
GRN WIRE
HIND
HOT AT ALL TIMES
HSW
ILL
J/C 5 (C-209, C-208)
J/C 9 (C-135)
LCD BRAKE WARNING ELECTRIC PARKING BRAKE WARNING
LEFT ELECTRIC PARKING BRAKE ACTUATOR
LOCK
LT BLU WIRE
MRL+
MRR
ON OFF
PIND
PNK WIRE
RED WIRE
RELAY ENERGIZED
RELEASE
RIGHT ELECTRIC PARKING BRAKE ACTUATOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Electronic parking brake circuit -> LEFT ELECTRIC PARKING BRAKE ACTUATOR
