Mitsubishi Eclipse Cross I (2017-2022) information switch ind Wiring diagram
This page shows the only wiring diagram for the component.information switch ind, which is found in the car Mitsubishi Eclipse Cross I (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram information switch ind (1 of 1)
AUDIO AMPLIFIER
BLK WIRE
BLU WIRE
C-128
C-243
C-251
DFR-
DSI-
DSO+
ECALL RELAY BOX ASSEMBLY
ECALL SPEAKER
ECALL, BCALL SWITCH
ESI+
ESO
GRN WIRE
IND (GREEN)
IND (RED) WIRE
INFORMATION SWITCH
INFORMATION SWITCH ILL (AMBER)
INFORMATION SWITCH IND
J/C 11 (C-126)
J/C 12 (C-127)
J/C 9 (C-135)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL/BLU WIRE
PPL/RED WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
SOS SWITCH
SOS SWITCH ILL (RED) WIRE
SOS SWITCH IND
VIO WIRE
W/ AUDIO AMPLIFIER
W/O AUDIO AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Telematics circuit (2 of 2) -> INFORMATION SWITCH IND
