Mitsubishi Eclipse Cross I (2017-2022) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Mitsubishi Eclipse Cross I (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (81 of 95)

BLK WIRE BRN WIRE C-243 C-418 ETACS-ECU FRONT LIGHT SENSOR FUSE 22 GRY WIRE HOT W/ ACC RELAY 2 ENERGIZED INSIDE REAR VIEW MIRROR ASSEMBLY J/C 5 (C-209) NCA WIRE REAR RIGHT SENSOR VIO WIRE

Go to component -> Automatic day/night mirror circuit, w/o universal garage door opener -> BLK WIRE

blk wiring diagram (82 of 95)

BLK WIRE BRN WIRE C-243 C-403 C-418 ETACS-ECU FRONT LIGHT SENSOR FUSE 19 FUSE 22 GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY 2 ENERGIZED INSIDE REAR VIEW MIRROR ASSEMBLY J/C 5 (C-209) J/C 7 (C-206) (CENTER OF DASH) NCA WIRE REAR RIGHT SENSOR SWITCHES, INDICATORS VIO WIRE

Go to component -> Automatic day/night mirror circuit, w/ universal garage door opener -> BLK WIRE

blk wiring diagram (83 of 95)

+ECU AUTO- HOLD BLK WIRE BLU WIRE BRAKE AUTO HOLD LIGHT IND BRAKE AUTO HOLD SWITCH BRAKE WARNING LIGHT IND BRN WIRE C-151 C-208 C-209 C-227 C-29 C-402 CAN L CANH C-226 COMBINATION METER COMPUTER DATA LINES SYSTEM D-27 D-28 DASH GROUNDING J/C (C-202) ELECTRIC PARKING BRAKE ECU ELECTRIC PARKING BRAKE SWITCH ELECTRIC PARKING BRAKE WARNING LIGHT IND ENGINE COMPARTMENT RELAY BOX ETACS-ECU FUSE 15 FUSE 25 FUSIBLE LINK 1 FUSIBLE LINK 2 GRN WIRE HIND HOT AT ALL TIMES HSW ILL J/C 5 (C-209, C-208) J/C 9 (C-135) LCD BRAKE WARNING ELECTRIC PARKING BRAKE WARNING LEFT ELECTRIC PARKING BRAKE ACTUATOR LOCK LT BLU WIRE MRL+ MRR ON OFF PIND PNK WIRE RED WIRE RELAY ENERGIZED RELEASE RIGHT ELECTRIC PARKING BRAKE ACTUATOR VIO WIRE WHT WIRE YEL WIRE

Go to component -> Electronic parking brake circuit -> BLK WIRE

blk wiring diagram (84 of 95)

+B C-21 BLK WIRE BRN WIRE C-149 C-21-1 C-22 C-23 C-24 C-402 C-414 CAN DRIVE CIRCUIT CAN L COMBINATION METER COMPUTER DATA LINES SYSTEM DASH GROUNDING J/C (C-202) ELECTRIC POWER STEERING SYSTEM WARNING ELECTRIC POWER STEERING SYSTEM WARNING LIGHT IND EPS-ECU (ON STEERING COLUMN) ETACS-ECU FUSE 15 FUSIBLE LINK 38 FUSIBLE LINK BOX GRN WIRE HOT AT ALL TIMES HOT W/ INTERFACE CIRCUIT J/C 1 (C-01) J/C 8 (C-103) LCD LT BLU WIRE MOTOR NCA WIRE PNK CAN-H WIRE RESOLVER TORQUE SENSOR WHT WIRE YEL WIRE

Go to component -> Electronic power steering circuit -> BLK WIRE

blk wiring diagram (85 of 95)

BLK WIRE BLU WIRE C-128 C-241 C-403 C-414 CONTROL CIRCUIT DOOR MIRROR FOLD RELAY DOOR MIRROR UNFOLD RELAY ETACS-ECU F-09 FUSE 5 GRY WIRE HOT AT ALL TIMES J/C 3 (C-105) LEFT DOOR MIRROR ASSEMBLY LT GRN WIRE MRR NCA WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/RED WIRE PPL/YEL WIRE RED WIRE REMOTE CONTROLLED MIRROR SWITCH RETRACTOR SWITCH RIGHT DOOR MIRROR ASSEMBLY UNFOLD/FOLD MOTOR W/O SIDE VIEW CAMERA W/ SIDE VIEW CAMERA

Go to component -> Fold-back mirrors circuit -> BLK WIRE

blk wiring diagram (86 of 95)

ACC RELAY 3 AUTO BLK WIRE BLU WIRE BRN WIRE C-243 C-29 C-402 C-403 C-405 C-412 C-414 C-417 C-419 CAN DRIVE CIRCUIT COLUMN ECU COLUMN SWITCH COMBINATION METER COMPUTER DATA LINES SYSTEM DASH GROUNDING J/C (C-202) E-05 ETACS-ECU FUSE 15 FUSE 18 FUSE 4 GRN WIRE HOT AT ALL TIMES INTERFACE CIRCUIT J/C 4 (C-104) J/C 8 (C-103) LCD LIGHTING CONTROL SENSOR LIN DRIVE CIRCUIT LT BLU WIRE MFSW MIST OFF PNK WIRE PPL REAR WINDOW WASHER RELAY RED WIRE VIO WIRE W/O RAIN SENSITIVE AUTO WIPER W/ RAIN SENSITIVE AUTO WIPER WASHER FLUID LEVEL WARNING DISPLAY WASHER MOTOR WHT WIRE WINDSHIELD INTERMITTENT WIPER INTERVAL ADJUSTING KNOB WINDSHIELD RAIN SENSITIVE WIPER FUNCTION ADJUSTING KNOB WINDSHIELD WASHER RELAY WINDSHIELD WASHER SWITCH WINDSHIELD WASHER TANK FLUID LEVEL SENSOR WINDSHIELD WIPER AUTOMATIC STOP RELAY WINDSHIELD WIPER MOTOR WINDSHIELD WIPER SPEED SWITCHING RELAY WINDSHIELD WIPER SWITCH YEL WIRE

Go to component -> Front wiper/washer circuit -> BLK WIRE

blk wiring diagram (87 of 95)

BLIND SPOT WARNING LIGHT BLK WIRE BLU WIRE C-241 C-414 C-418 CONTROL CIRCUIT DEFOGGER SYSTEM ETACS-ECU FOLD-BACK MIRRORS CIRCUIT FUSE 22 GRY WIRE HEATER HORIZONTAL MOVEMENT MOTOR HOT W/ ACC RELAY 2 ENERGIZED J/C 5 (C-209) LEFT DOOR MIRROR ASSEMBLY LEFT SIDE TURN SIGNAL LIGHT LEFT SIDE VIEW CAMERA MRR NAVIGATION SYSTEM NCA WIRE PNK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/RED WIRE PPL/VIO WIRE PPL/YEL WIRE RED WIRE UNFOLD/FOLD MOTOR VERTICAL MOVEMENT MOTOR W/O SIDE VIEW CAMERA W/ SIDE VIEW CAMERA WHT WIRE

Go to component -> Power mirrors circuit (1 of 2) -> BLK WIRE

blk wiring diagram (88 of 95)

BLIND SPOT WARNING LIGHT BLK WIRE BLU WIRE BRN WIRE C-128 C-241 CONTROL CIRCUIT DEFOGGER SYSTEM DOWN F-09 FOLD-BACK MIRRORS CIRCUIT GRN WIRE GRY WIRE HEATER HORIZONTAL MOVEMENT MOTOR ILL LEFT LEFT OFF LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE OPERATION SWITCH PNK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/RED WIRE PPL/VIO WIRE PPL/YEL WIRE RED WIRE REMOTE CONTROLLED MIRROR SWITCH RETRACTOR SWITCH RIGHT RIGHT DOOR MIRROR ASSEMBLY RIGHT SIDE TURN SIGNAL LIGHT RIGHT SIDE VIEW CAMERA RIGHT/LEFT CHANGEOVER SWITCH UNFOLD/FOLD MOTOR VERTICAL MOVEMENT MOTOR VIO WIRE W/O SIDE VIEW CAMERA W/ SIDE VIEW CAMERA WHT WIRE

Go to component -> Power mirrors circuit (2 of 2) -> BLK WIRE

blk wiring diagram (89 of 95)

A-109 A-110 BLK WIRE BLU WIRE BRN WIRE C-29 C-31 C-402 C-403 C-410 C-412 C-414 C-417 CAN DRIVE CIRCUIT COLUMN ECU COLUMN SWITCH COMPUTER DATA LINES SYSTEM D-108 DASH GROUNDING J/C (C-202) ETACS-ECU FUSE 15 FUSE 18 FUSE 20 FUSE 4 FUSE 8 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY 3 ENERGIZED INHR CANH INTERFACE CIRCUIT J/C 4 (C-104) J/C 8 (C-103) LIN DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE OFF PNK WIRE POWER DISTRIBUTION SYSTEM REAR WASHER SWITCH REAR WINDOW WASHER RELAY REAR WIPER MOTOR (CENTER OF LIFTGATE) REAR WIPER RELAY REAR WIPER SWITCH RED WIRE TRANSAXLE CONTROL MODULE TRANSMISSION RANGE SWITCH WASHER MOTOR WHT WIRE WINDSHIELD WASHER RELAY WIPER/WASHER SWITCH YEL WIRE

Go to component -> Rear wiper/washer circuit -> BLK WIRE

blk wiring diagram (90 of 95)

BLK WIRE BRN WIRE C-208 C-209 C-402 C-417 C-418 C-419 C-420 DASH GROUNDING J/C (C-202) ETACS-ECU FUSE 14 FUSE 15 FUSE 22 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC ACC RELAY 2 ENERGIZED J/C 3 (C-105) J/C 4 (C-104) J/C 5 (C-209, C-208) J/C 9 (C-135) KEY INTERLOCK SOLENOID KEY LOCK RELAY LT GRN WIRE NCA WIRE P RANGE DETECTION SWITCH RED WIRE RELAY ENERGIZED SELECTOR LEVER ASSEMBLY SHIFT LOCK SOLENOID SLSO STOP LIGHT CONTROL CIRCUIT STOP LIGHT SWITCH VIO WIRE

Go to component -> Shift interlock circuit -> BLK WIRE
