Radio circuit, hatchback 3-door w/ base radio w/o active sound design for MINI John Cooper Works III facelift (2018-2021)

ANTENNA DIVERSITY BLK/BRN WIRE BLK/RED WIRE BLU/BRN WIRE BLU/RED WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 GPS AERIAL GRN WIRE GRN/BLU WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL NAVIGATION NCA WIRE REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF) REAR VIEW CAMERA RED/BRN WIRE RED/YEL WIRE SELECTOR SWITCH TELEPHONE AERIAL USB/ETHERNET VIO WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIRELESS CHARGING SHELF ANTENNA AMPLIFIER WIRELESS CHARGING STORAGE YEL WIRE

BASIC VERSION BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/GRN WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT GRN WIRE GRY/RED WIRE HIGH VERSION MICROPHONE MICROPHONE 2 (W/ VOICE INPUT) (RIGHT FRONT OF HEADLINER) NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE TELEMATIC COMMUNICATION BOX (RIGHT SIDE OF DASH) VIO WIRE W/ NAVIGATION W/ TELEMATICS W/O NAVIGATION W/O TELEMATICS WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

BASE PLATE FAN BLK/BRN WIRE BLK/RED WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FRONT POWER DISTRIBUTION BOX FUSE 101 FUSE 51 FUSE 68 FUSE 80 HOT AT ALL TIMES HOT W/ LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER NCA WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT BASS SPEAKER RIGHT FRONT MID-RANGE SPEAKER VIO WIRE W/ WIRELESS CHARGING STORAGE W/O WIRELESS CHARGING STORAGE WHT WIRE WHT/GRN WIRE WHT/RED WIRE

ANTENNA DIVERSITY ANTENNA SIGNAL AMPLIFIER 2 AUX-IN CONNECTION USB CONNECTION BASE PLATE BLK WIRE BLU WIRE BRN (OR BRN/ORG) WIRE BRN WIRE CAR SHARING MODULE CENTER CONSOLE COMPUTER DATA LINES SYSTEM DVD CHANGER FRONT POWER DISTRIBUTION BOX FUSE 87 GRN WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL ID READER INSTRUMENT PANEL LEFT SIDE WINDOW ANTENNA NAVIGATION NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT SIDE WINDOW ANTENNA SELECTOR SWITCH USB/ETHERNET VIO WIRE WHT/GRN WIRE WHT/RED WIRE WLAN ANTENNA YEL WIRE YEL/BRN WIRE YEL/RED WIRE
