MINI John Cooper Works III facelift (2018-2021) right convertible top raised hall effect sensor Wiring diagram
This page shows the only wiring diagram for the component.right convertible top raised hall effect sensor, which is found in the car MINI John Cooper Works III facelift (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right convertible top raised hall effect sensor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP MODULE
COWL PANEL LOCK DRIVE OPEN HALL EFFECT SENSOR
DIRECTION INCREMENTAL ENCODER HALL EFFECT SENSOR
FOLDING SUNROOF POSITION HALL EFFECT SENSOR
FOLDING SUNROOF, CONVERTIBLE TOP LOCKING DRIVE
FOLDING SUNROOF, SOFT TOP LOCKING DRIVE UNIT
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INCREMENTAL TRANSDUCER HALL EFFECT SENSOR
LEFT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
NCA WIRE
POSITION INCREMENTAL ENCODER HALL EFFECT SENSOR
RED WIRE
RIGHT CONVERTIBLE TOP DRIVE UNIT
RIGHT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
SOFT TOP STOWED HALL EFFECT SENSOR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component: -> Convertible top circuit (2 of 2) -> RIGHT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
