MINI John Cooper Works III facelift (2018-2021) coolant temp sensor sig Wiring diagram
This page shows the only wiring diagram for the component.coolant temp sensor sig, which is found in the car MINI John Cooper Works III facelift (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant temp sensor sig (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
CAN BUS SIG
CHARACTERISTIC MAP THERMOSTAT ACT
COMPUTER DATA LINES SYSTEM
COOLANT TEMP SENSOR SIG
COOLANT TEMPERATURE SENSOR
DIGITAL MOTOR ELECTRONICS
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN ACT
ELECTRIC FAN CUTOFF RELAY
ELECTRIC FAN RELAY
FUSE 401
FUSE 7
FUSE BOX
HOT AT ALL TIMES
INTEGRATED SUPPLY MODULE
LIN BUS SIG
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP 2
MAP THERMOSTAT
PWR SPLY ELECTRIC FAN ACT CUT-OUT RELAY
RADIATOR BLIND DRIVE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/VIO WIRE
SENSOR GND
SPLY CHARACTERISTIC MAP THERMOSTAT
SPLY TURBOCHARGER COOLANT PUMP
TURBOCHARGER COOLANT PUMP
TURBOCHARGER COOLANT PUMP ACT
TURBOCHARGER COOLANT PUMP GND
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component: -> Automatic a/c circuit (4 of 4) -> COOLANT TEMP SENSOR SIG
