MINI John Cooper Works III facelift (2018-2021) auxiliary stop lamp Wiring diagram
This page shows the only wiring diagram for the component.auxiliary stop lamp, which is found in the car MINI John Cooper Works III facelift (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary stop lamp (1 of 1)
AUXILIARY STOP LAMP
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER ASSISTANCE SYSTEM OPERATING UNIT W/ HAZARD WARNING SWITCH
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT FOG LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT LICENSE PLATE LAMP
LEFT REAR SIDE MARKER LIGHT
NCA WIRE
ORG/ WIRE
OUTER TAILGATE BUTTON
RIGHT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT LICENSE PLATE LAMP
RIGHT REAR SIDE MARKER LIGHT
SIDE LAMP
VIO/GRY WIRE
VIO/YEL WIRE
W/ LED W/O LED
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> AUXILIARY STOP LAMP
