MINI John Cooper Works II facelift (2010-2013) Transmission circuit

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CAR ACCESS SYSTEM COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE TRANSMISSION CONTROL UNIT TRANSMISSION MANAGEMENT VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/VIO WIRE

ALL-WHEEL DRIVE VEHICLE CLUTCH BLK/RED WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DYNAMIC STABILITY CONTROL (DSC) GEAR INDICATOR LIGHTING GRN/GRY WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE LEFT ROCKER SWITCH NCA WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT ROCKER SWITCH SELECTOR LEVER POSITION SWITCH STEERING COLUMN SWITCH CLUSTER WHT WIRE WHT/BLU WIRE YEL/BLK WIRE YEL/BRN WIRE
