MINI John Cooper Works II facelift (2010-2013) Courtesy lamps circuit, convertible w/ interior lights package

BLU WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPE DRIVER'S DOOR COURTESY LIGHTING DRIVER'S DOOR HANDLE PLATE LIGHTING FOOTWELL MODULE FRONT INTERIOR LIGHT GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT JUNCTION BOX LEFT B-PILLAR AMBIENT LIGHTING LEFT FRONT FOOTWELL LIGHT ORG/ WIRE ORG/GRN WIRE PASSENGER'S DOOR COURTESY LIGHTING PASSENGER'S DOOR HANDLE PLATE LIGHTING RED WIRE RED/BLU WIRE RED/GRN WIRE RELAY ENERGIZED RIGHT B-PILLAR AMBIENT LIGHTING RIGHT FRONT FOOTWELL LIGHT ROOF OPERATING UNIT TOP LIGHT VIO WIRE VIO/GRY WIRE WHT WIRE WHT/YEL WIRE YEL WIRE

BOOT LID, CENTRAL LOCKING DRIVE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COUPE COUPE CONVERTIBLE DRIVER'S DOOR ENTRANCE LIGHT GLOVE COMPARTMENT LIGHT GRY WIRE LEFT FRONT MAKE- UP MIRROR LIGHT LUGGAGE COMPARTMENT LIGHT PASSENGER'S DOOR ENTRANCE LIGHT REAR INTERIOR LIGHT RED/BLU WIRE RIGHT FRONT MAKE- UP MIRROR LIGHT VIO WIRE VIO/GRY WIRE VIO/YEL WIRE YEL WIRE
