MINI John Cooper Works Countryman III (2023-2024) interior rear lid button Wiring diagram
This page shows the only wiring diagram for the component.interior rear lid button, which is found in the car MINI John Cooper Works Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior rear lid button (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/YEL (OR ORG) WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEAD LOCKING RELAY
DRIVER'S DOOR SWITCH BLOCK
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 11
FUSE 3
FUSE 7
GRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
INTERIOR REAR LID BUTTON
NCA WIRE
ORG/ WIRE
OUTER TAILGATE BUTTON
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
TAILGATE BUTTON ON INSIDE OF TRUNK LID
TAILGATE LOCK
TRUNK LID POWERTRAIN AUTOMATIC SOFT CLOSE SYSTEM
UNLOCKING RELAY
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Trunk & fuel door release circuit (2 of 2) -> INTERIOR REAR LID BUTTON
