MINI John Cooper Works Countryman III (2023-2024) hot w/ power supply sensors/actuators relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ power supply sensors/actuators relay energized, which is found in the car MINI John Cooper Works Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ power supply sensors/actuators relay energized (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR
CRANKCASE COOLANT SHUTOFF VALVE
CRANKCASE TEMPERATURE SENSOR
DIGITAL MOTOR ELECTRONICS
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN CUTOFF RELAY (LEFT FRONT OF FRONT COMPT)
ELECTRIC FAN RELAY
EXCEPT HYBRID
FUSE 1
FUSE 401
FUSE 7
FUSE 8
FUSE BOX
HEAT MANAGEMENT MODULE
HOT AT ALL TIMES
HOT W/ DME MAIN RELAY ENERGIZED
HOT W/ POWER SUPPLY SENSORS/ACTUATORS RELAY ENERGIZED
INTEGRATED SUPPLY MODULE
MAP THERMOSTAT
RADIATOR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
TURBOCHARGER COOLANT PUMP
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> HOT W/ POWER SUPPLY SENSORS/ACTUATORS RELAY ENERGIZED
