MINI John Cooper Works Countryman II facelift (2020-2024) w/o removable thigh support w/ removable thigh support Wiring diagram
This page shows the only wiring diagram for the component.w/o removable thigh support w/ removable thigh support, which is found in the car MINI John Cooper Works Countryman II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o removable thigh support w/ removable thigh support (1 of 1)
AIR CONDITIONING
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SEAT MODULE
DRIVER THIGH SUPPORT HEATING
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT SURFACE HEATING
FRONT POWER DISTRIBUTION BOX
FUSE 127
GRN WIRE
NCA WIRE
RED WIRE
RED/GRN WIRE
RELAY 2 ENERGIZED
VIO WIRE
W/O REMOVABLE THIGH SUPPORT W/ REMOVABLE THIGH SUPPORT
WHT WIRE
YEL WIRE
Go to component: -> Heated seats circuit, w/ memory -> W/O REMOVABLE THIGH SUPPORT W/ REMOVABLE THIGH SUPPORT
