MINI John Cooper Works Clubman II (2015-2019) w/ led countryman cooper clubman w/ bulb Wiring diagram

This page shows the only wiring diagram for the component.w/ led countryman cooper clubman w/ bulb, which is found in the car MINI John Cooper Works Clubman II (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram w/ led countryman cooper clubman w/ bulb (1 of 1)

Wiring diagram w/ led countryman cooper clubman w/ bulb for MINI John Cooper Works Clubman II (2015-2019)

Get access

BLU WIRE BOOT LID/ TAILGATE LOCK BRN WIRE BRN/BLK WIRE CIRCUIT DRIVER'S SIDE REAR INNER DOOR HANDLE LIGHTING ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FRONT PASSENGER DOOR POCKET LIGHTING FRONT PASSENGER DOOR POCKET LIGHTING 2 GLOVE COMPARTMENT LIGHT GLOVE COMPARTMENT LIGHT SWITCH GRN WIRE GRY/RED WIRE GRY/VIO WIRE ILLUMINATION INSTRUMENT INSTRUMENT ILLUMINATION CIRCUIT LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPARTMENT LIGHT 2 ORG/ WIRE RAIN/LIGHT/ SOLAR CONDENSATION SENSOR RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT SPLIT DOOR LOCK THIRD ROW SEATS INTERIOR LIGHT VIO/YEL WIRE W/ LED COUNTRYMAN COOPER CLUBMAN W/ BULB WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component: -> Courtesy lamps circuit (2 of 4) -> W/ LED COUNTRYMAN COOPER CLUBMAN W/ BULB
