MINI Cooper III facelift (2018-2021) countryman except countryman w/ trailer module w/o trailer module Wiring diagram
This page shows the only wiring diagram for the component.countryman except countryman w/ trailer module w/o trailer module, which is found in the car MINI Cooper III facelift (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram countryman except countryman w/ trailer module w/o trailer module (1 of 1)
BASE PLATE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
CONVERTIBLE TOP MODULE
COUNTRYMAN EXCEPT COUNTRYMAN W/ TRAILER MODULE W/O TRAILER MODULE
DRIVER SEAT MODULE
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SEAT HEATING ELECTRONICS
EXCEPT CONVERTIBLE
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
NCA WIRE
PARKING MANEUVERING ASSISTANT
PNK/BLK WIRE
RED WIRE
REMOTE CONTROL RECEIVER
ROOF FUNCTION CENTER
SIREN, TILT SENSOR
TAILGATE FUNCTION MODULE
TRAILER MODULE
TRAILER SOCKET
VIO WIRE
VIO/YEL WIRE
W/O TERMINATING RESISTOR
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> High/low bus circuit (2 of 4) -> COUNTRYMAN EXCEPT COUNTRYMAN W/ TRAILER MODULE W/O TRAILER MODULE
