Radio circuit, w/ hifi radio & active sound design for MINI Cooper III facelift 2 (2021-2024)

BLK/VIO WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 GPS ANTENNA GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL NAVIGATION NCA WIRE REAR VIEW CAMERA RED/BRN WIRE RED/YEL WIRE SELECTOR SWITCH TELEPHONE ANTENNA USB/ETHERNET VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ ANTENNA AMPLIFIER W/O ANTENNA AMPLIFIER WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIRELESS CHARGING SHELF ANTENNA AMPLIFIER WIRELESS CHARGING STORAGE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

ACTIVE SOUND DESIGN BLK WIRE BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BRN (OR BRN/ORG) WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/WHT WIRE GRY/YEL WIRE MICROPHONE 2 (W/ VOICE INPUT) (RIGHT FRONT OF HEADLINER) NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO (OR RED/YEL) WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BASIC BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN/GRN WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE CENTRAL INSTRUMENT FRONT CENTER MID-RANGE SPEAKER FRONT CENTER TWEETER FRONT POWER DISTRIBUTION BOX FUSE 80 FUSE 91 GRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT W/ LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER MICROPHONE NCA WIRE RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT BASS SPEAKER TELEMATIC COMMUNICATION BOX (RIGHT SIDE OF DASH) VIO WIRE VIO/GRY WIRE VIO/WHT WIRE W/ NAVIGATION W/ TELEMATICS W/O NAVIGATION W/O TELEMATICS W/O WIRELESS CHARGING WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED (OR BLK/RED) WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BASE PLATE FAN BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN (OR BRN/ORG) WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FRONT POWER DISTRIBUTION BOX FUSE 101 FUSE 129 FUSE 51 FUSE 68 GRN/GRY WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HIFI AMPLIFIER (BEHIND LEFT REAR TRIM PANEL) HOT AT ALL TIMES HOT W/ LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER NCA WIRE RED WIRE RED/BRN WIRE RED/GRN WIRE RED/YEL WIRE RELAY 2 ENERGIZED RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER VIO WIRE VIO/GRY WIRE VIO/WHT WIRE W/ WIRELESS CHARGING STORAGE W/O WIRELESS CHARGING STORAGE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

AERIAL DIVERSITY (W/ ALARM SYSTEM LED) ANTENNA DIVERSITY ANTENNA SIGNAL AMPLIFIER 2 BASE PLATE BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN (OR BRN/ORG) WIRE BRN WIRE CAR SHARING MODULE CENTER CONSOLE CLUBMAN, CONVERTIBLE COMPUTER DATA LINES SYSTEM DVD CHANGER FRONT POWER DISTRIBUTION BOX FUSE 87 GRN WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL ID READER INSTRUMENT PANEL LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER NAVIGATION NCA WIRE ORG/ WIRE REAR BUMPER ANTENNA REAR SPOILER ANTENNA REAR WINDOW ANTENNA RED WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT SIDE WINDOW ANTENNA SELECTOR SWITCH USB CONNECTION USB/ETHERNET VIO WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WLAN ANTENNA YEL WIRE YEL/BRN WIRE YEL/RED WIRE
