MINI Cooper III facelift 2 (2021-2024) telephone antenna Wiring diagrams
This page contains all the electrical diagrams for the component. telephone antenna, in which he is found in the car MINI Cooper III facelift 2 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram telephone antenna (1 of 10)
ANTENNA DIVERSITY
BLK/BRN WIRE
BLK/RED WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
NAVIGATION
NCA WIRE
REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF)
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
Go to component -> Navigation circuit, hatchback 3-door w/ base radio w/o active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (2 of 10)
ANTENNA DIVERSITY
BLK/BRN WIRE
BLK/RED WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLUETOOTH ANTENNA
BRN WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRY/BRN WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HOT W/ TERMINAL
NCA WIRE
REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF)
REAR VIEW CAMERA (CENTER OF TAILGATE)
RED/BRN WIRE
RED/YEL WIRE
TELEPHONE ANTENNA
VIO WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
Go to component -> Navigation circuit, hatchback 5-door w/ base radio w/o active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (3 of 10)
ANTENNA DIVERSITY
BLK/VIO WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
NAVIGATION
NCA WIRE
REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF)
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, w/ base radio & active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (4 of 10)
BLK/VIO WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
NAVIGATION
NCA WIRE
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, w/ hifi radio & active sound design (1 of 5) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (5 of 10)
BLK WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
MICROPHONE 2 (W/ VOICE INPUT)
NAVIGATION
NCA WIRE
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, w/ hifi radio w/o active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (6 of 10)
ANTENNA DIVERSITY
BLK/BRN WIRE
BLK/RED WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
NAVIGATION
NCA WIRE
REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF)
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
Go to component -> Radio circuit, hatchback 3-door w/ base radio w/o active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (7 of 10)
ANTENNA DIVERSITY
BLK/BRN WIRE
BLK/RED WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLUETOOTH ANTENNA
BRN WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRY/BRN WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HOT W/ TERMINAL
NCA WIRE
REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF)
REAR VIEW CAMERA (CENTER OF TAILGATE)
RED/BRN WIRE
RED/YEL WIRE
TELEPHONE ANTENNA
VIO WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
Go to component -> Radio circuit, hatchback 5-door w/ base radio w/o active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (8 of 10)
ANTENNA DIVERSITY
BLK/VIO WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
NAVIGATION
NCA WIRE
REAR SPOILER ANTENNA (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF)
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, w/ base radio & active sound design (1 of 4) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (9 of 10)
BLK/VIO WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
NAVIGATION
NCA WIRE
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, w/ hifi radio & active sound design (1 of 5) -> TELEPHONE ANTENNA
Wiring diagram telephone antenna (10 of 10)
BLK WIRE
BLUETOOTH ANTENNA
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 61
FUSE 79
GPS ANTENNA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
HEAD UNIT BASIS W/
HOT W/ TERMINAL
MICROPHONE 2 (W/ VOICE INPUT)
NAVIGATION
NCA WIRE
REAR VIEW CAMERA
RED/BRN WIRE
RED/YEL WIRE
SELECTOR SWITCH
TELEPHONE ANTENNA
USB/ETHERNET
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W/ ANTENNA AMPLIFIER
W/O ANTENNA AMPLIFIER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, w/ hifi radio w/o active sound design (1 of 4) -> TELEPHONE ANTENNA
