MINI Cooper III facelift 2 (2021-2024) high voltage battery unit refrigerant shutoff valve Wiring diagram
This page shows the only wiring diagram for the component.high voltage battery unit refrigerant shutoff valve, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high voltage battery unit refrigerant shutoff valve (1 of 1)
AIR CONDITIONING COMPRESSOR (ELECTRIC)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CONVENIENCE CHARGING ELECTRONICS (RIGHT FRONT OF ENGINE COMPT)
ELECTRIC AUXILIARY HEATER
ELECTRIC AUXILIARY HEATER TEMPERATURE SENSOR
ELECTRICAL MACHINE ELECTRONICS
EXCEPT HYBRID
FRONT POWER DISTRIBUTION BOX
FUSE 130
FUSE 50
FUSE 72
FUSE 74
FUSE 83
HIGH VOLTAGE BATTERY UNIT REFRIGERANT SHUTOFF VALVE
HIGH-VOLTAGE BATTERY UNIT
HOT W/
HOT W/ TERMINAL
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP 2
NCA WIRE
PASSENGER COMPARTMENT REFRIGERANT SHUTOFF VALVE
RADIATOR BLIND DRIVE
RED WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY 2 ENERGIZED
RELAY ENERGIZED
TURBOCHARGER COOLANT PUMP
VIO WIRE
VIO/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, except electric (3 of 4) -> HIGH VOLTAGE BATTERY UNIT REFRIGERANT SHUTOFF VALVE
