MINI Cooper III facelift 2 (2021-2024) heat pump circuit changeover valve 3 Wiring diagram
This page shows the only wiring diagram for the component.heat pump circuit changeover valve 3, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heat pump circuit changeover valve 3 (1 of 1)
AUXILIARY WATER PUMP
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 83
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEAT PUMP CIRCUIT CHANGEOVER VALVE 3
HEAT PUMP CIRCUIT EXPANSION VALVE
HEAT PUMP CIRCUIT TEMPERATURE SENSOR
HEAT PUMP CONTROLLER
HOT W/
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
REFRIGERANT PRESSURE TEMPERATURE SENSOR
REFRIGERANT PRESSURE TEMPERATURE SENSOR 2
RELAY ENERGIZED
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Heat pump circuit (1 of 2) -> HEAT PUMP CIRCUIT CHANGEOVER VALVE 3
