MINI Cooper III facelift 2 (2021-2024) fresh air/recirculated air flap motor Wiring diagrams

AIR DISTRIBUTION FLAP MOTOR AUC SENSOR BASIC BLOWER OUTPUT STAGE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE DEFROSTER FLAP MOTOR FOOTWELL FLAP MOTOR FRESH AIR/RECIRCULATED AIR FLAP MOTOR FRONT POWER DISTRIBUTION BOX FUSE 34 FUSE 53 GRN/RED WIRE HOT AT ALL TIMES HOT W/ LEFT MIXED AIR FLAP MOTOR MIXED AIR FLAP MOTOR NCA WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT MIXED AIR FLAP MOTOR WHT/BRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/VIO WIRE

AIR DISTRIBUTION FLAP MOTOR AIR DISTRIBUTION MICROSWITCH BASIC BLK WIRE BLOWER MOTOR BLOWER OUTPUT STAGE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE DEFROSTER FLAP MOTOR EVAPORATOR TEMPERATURE SENSOR EXCEPT HYBRID FOOTWELL FLAP MOTOR FOOTWELL TEMPERATURE SENSOR (HIGH) (LOWER LEFT SIDE OF REAR OF HVAC UNIT) FRESH AIR/RECIRCULATED AIR FLAP MOTOR FRONT ELECTRIC AUXILIARY HEATER FRONT POWER DISTRIBUTION BOX FUSE 123 FUSE 34 FUSE 405 FUSE BOX GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LEFT MIXED AIR FLAP MOTOR MIXING AIR FLAP MOTOR (BASIC) (ON LOWER RIGHT SIDE OF HVAC UNIT) NCA WIRE RED WIRE RED/BRN WIRE RED/WHT WIRE RELAY 2 ENERGIZED RIGHT MIXED AIR FLAP MOTOR VENTILATION TEMPERATURE SENSOR YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/VIO WIRE
