MINI Cooper III facelift 2 (2021-2024) folding sunroof, soft top locking drive unit Wiring diagram
This page shows the only wiring diagram for the component.folding sunroof, soft top locking drive unit, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram folding sunroof, soft top locking drive unit (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/VIO WIRE
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP MODULE
COWL PANEL LOCK DRIVE OPEN HALL EFFECT SENSOR
DIRECTION INCREMENTAL ENCODER HALL EFFECT SENSOR
FOLDING SUNROOF POSITION HALL EFFECT SENSOR
FOLDING SUNROOF, CONVERTIBLE TOP LOCKING DRIVE
FOLDING SUNROOF, SOFT TOP LOCKING DRIVE UNIT
GRN/BRN WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INCREMENTAL TRANSDUCER HALL EFFECT SENSOR
NCA WIRE
POSITION INCREMENTAL ENCODER HALL EFFECT SENSOR
RED WIRE
RED/WHT WIRE
RIGHT CONVERTIBLE TOP DRIVE UNIT (BEHIND RIGHT CONVERTIBLE REAR TRIM PANEL)
RIGHT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
SOFT TOP STOWED HALL EFFECT SENSOR
STOWAGE LOCK CLOSED HALL EFFECT SENSOR
VIO/BLK WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Convertible top circuit (2 of 2) -> FOLDING SUNROOF, SOFT TOP LOCKING DRIVE UNIT
