MINI Cooper III facelift 2 (2021-2024) except hatchback 3 door, convertible Wiring diagram
This page shows the only wiring diagram for the component.except hatchback 3 door, convertible, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except hatchback 3 door, convertible (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/YEL (OR BRN/BLK) WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COUNTRYMAN, HATCHBACK 3 DOOR, CONVERTIBLE
DOOR LOCKS
DOOR LOCKS SYSTEM
DRIVER POWER WINDOW DRIVE
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SIDE REAR POWER WINDOW DRIVE
DRIVER'S SIDE REAR POWER WINDOW SWITCH
EXCEPT HATCHBACK 3 DOOR, CONVERTIBLE
FRONT PASSENGER DOOR POWER WINDOW SWITCH
FRONT PASSENGER POWER WINDOW DRIVE
FRONT POWER DISTRIBUTION BOX
FUSE 1
FUSE 2
FUSE 4
FUSE 6
FUSE 69
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HATCHBACK 3-DOOR, CONVERTIBLE
HATCHBACK 5 DOOR, CLUBMAN
HOT AT ALL TIMES
HOT W/
ORG/ WIRE
PASSENGER'S SIDE REAR POWER WINDOW DRIVE
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
RED/GRY WIRE
RELAY ENERGIZED
SYSTEM
VIO WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit -> EXCEPT HATCHBACK 3 DOOR, CONVERTIBLE
