MINI Cooper III facelift 2 (2021-2024) electric steering lock Wiring diagram
This page shows the only wiring diagram for the component.electric steering lock, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electric steering lock (1 of 1)
AIR CONDITIONING
AIR CONDITIONING COMPRESSOR (ELECTRIC)
BASIC
BLK (OR BLU) WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN/BLK WIRE
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CRASH SAFETY MODULE
DRIVER ASSISTANCE SYSTEM OPERATING UNIT W/ HAZARD WARNING SWITCH
DYNAMIC STABILITY CONTROL (DSC)
ELECTRIC
ELECTRIC AUXILIARY HEATER
ELECTRIC STEERING LOCK
ELECTROMECHANICAL POWER STEERING
FRONT POWER DISTRIBUTION BOX
FUSE 35
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL
LIGHT OPERATING UNIT
NCA WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/RED WIRE
RED WIRE
RED/WHT WIRE
RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH CLUSTER
STEERING COLUMN SWITCH CLUSTER
STEERING WHEEL MODULE
TELEMATIC COMMUNICATION BOX
VIO WIRE
VIO/YEL WIRE
W/ ELECTROMECHANICAL PARKING BRAKE
W/O ELECTROMECHANICAL PARKING BRAKE
W/O TERMINATING RESISTOR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> High/low bus circuit (1 of 4) -> ELECTRIC STEERING LOCK
