MINI Cooper III facelift 2 (2021-2024) driver's door inside handle light Wiring diagram
This page shows the only wiring diagram for the component.driver's door inside handle light, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door inside handle light (1 of 1)
BLU WIRE
BRN WIRE
DRIVER'S DOOR CONTOUR LIGHTING
DRIVER'S DOOR CONTOUR LIGHTING 2
DRIVER'S DOOR INSIDE HANDLE LIGHT
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE REAR DOOR CONTOUR LIGHTING
DRIVER'S SIDE REAR DOOR POCKET LIGHTING
DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
GRN WIRE
GRY/RED WIRE
INSTRUMENT ILLUMINATION CIRCUIT
ORG/ WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Courtesy lamps circuit (6 of 6) -> DRIVER'S DOOR INSIDE HANDLE LIGHT
