MINI Cooper III facelift 2 (2021-2024) driver seat lumbar support switch Wiring diagram
This page shows the only wiring diagram for the component.driver seat lumbar support switch, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat lumbar support switch (1 of 1)
BASE PLATE
BI-STABLE RELAY
BLK WIRE
BLU WIRE
BOOT LID/ TAILGATE LOCK
BRN WIRE
BRN/BLK WIRE
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONVERTIBLE TOP MODULE
DEADLOCKING RELAY
DIAGNOSTIC SOCKET
DRIVER ASSISTANCE SYSTEM OPERATING UNIT W/ HAZARD WARNING SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER'S DOOR LOCKING RELAY
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
ELECTRIC FAN CUTOFF RELAY
ELECTRIC FAN RELAY INTEGRATED SUPPLY MODULE
ELECTRIC FUEL PUMP CONTROL ELECTRONICS
ELECTRONIC TRANSMISSION CONTROL
FROM FRONT POWER DISTRIBUTION BOX (DIAGRAM 1 OF 4)
FROM FUSE 32 (DIAGRAM 1 OF 4)
FROM FUSE BOX (DIAGRAM 1 OF 4)
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 14
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 61
FUSE 66
FUSE 67
FUSE 69
FUSE 7
FUSE 70
FUSE 72
FUSE 73
FUSE 79
FUSE 81
FUSE 82
FUSE 9
FUSE 92
FUSE 93
FUSE 94
FUSE 96
GLOVE COMPARTMENT LIGHT
GRY/RED WIRE
HEAD UNIT
HEATING/AIR CONDITIONING SYSTEM
HIGH BASIC
LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
LIGHT OPERATING UNIT
LOCKING RELAY
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP 2
LUGGAGE COMPARTMENT LIGHT
NCA WIRE
OPTIONAL EXTRA SYSTEM
POWER WINDOW DRIVER RELAY
REAR LID BUTTON
REAR WINDOW HEATED RELAY
REAR WINDOW WIPER RELAY 2
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SELECTOR LEVER
STEERING COLUMN SWITCH CLUSTER
TAILGATE FUNCTION MODULE
TELEMATIC COMMUNICATION BOX
TO FRONT POWER DISTRIBUTION BOX (DIAGRAM 3 OF 4)
TO FUSE 62 (DIAGRAM 3 OF 4)
TRUNK COMPARTMENT LIGHT 2
UNLOCKING RELAY
VIO WIRE
VIO/BLU WIRE
W/ LIN BUS FUNCTION
WHT WIRE
WHT/VIO WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> DRIVER SEAT LUMBAR SUPPORT SWITCH
