MINI Cooper III facelift 2 (2021-2024) convertible top compartment floor microswitch Wiring diagram
This page shows the only wiring diagram for the component.convertible top compartment floor microswitch, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top compartment floor microswitch (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP COMPARTMENT FLOOR MICROSWITCH
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP MODULE
FRONT INTERIOR LIGHT
FRONT POWER DISTRIBUTION BOX
FUSE 93
FUSE 94
FUSE 96
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INCREMENTAL TRANSDUCER HALL EFFECT SENSOR
LEFT CONVERTIBLE TOP DRIVE UNIT
LEFT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Convertible top circuit (1 of 2) -> CONVERTIBLE TOP COMPARTMENT FLOOR MICROSWITCH
