MINI Cooper III facelift 2 (2021-2024) contact-free tailgate opening upper sensor Wiring diagram
This page shows the only wiring diagram for the component.contact-free tailgate opening upper sensor, which is found in the car MINI Cooper III facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram contact-free tailgate opening upper sensor (1 of 1)
BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BUMPER ANTENNA
COMPUTER DATA LINES SYSTEM
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
COOPER COUNTRYMAN
FUSE 12
GRY/BLK WIRE
GRY/RED WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
RED/VIO WIRE
WHT/BLU (OR WHT) WIRE
WHT/BLU WIRE
Go to component -> Contact-free tailgate opening circuit -> CONTACT-FREE TAILGATE OPENING UPPER SENSOR
