MINI Cooper III (2013-2018) Radio circuit, hatchback w/ base radio w/o active sound design

BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN WIRE CENTER CONSOLE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 FUSE 87 GRN WIRE GRY/RED WIRE HEAD UNIT HEAD UNIT BASIS W/ HOT W/ TERMINAL NAVIGATION NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE REVERSING CAMERA ROOF ANTENNA USB/ETHERNET VIO WIRE W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/GRN WIRE CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT DVD CHANGER GRN WIRE GRY/RED WIRE HEAD UNIT MICROPHONE MICROPHONE 2 (RIGHT FRONT OF ROOF) MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE VIO WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

BASE PLATE FAN BLK/BRN WIRE BLK/RED WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM CONTROLLER FRONT POWER DISTRIBUTION BOX FUSE 101 FUSE 51 FUSE 68 FUSE 80 GRN WIRE HOT AT ALL TIMES HOT W/ LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER NCA WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY 1 ENERGIZED RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER TOUCHBOX VIO WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE

ANTENNA DIVERSITY AUX-IN CONNECTION BASE PLATE BLK WIRE BLU WIRE BRN WIRE CAR SHARING MODULE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE HEAD UNIT HEAD UNIT BASIS W/ ID READER MOST DATA BUS CIRCUIT NAVIGATION NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/YEL WIRE ROOF ANTENNA TELEMATICS COMMUNICATION BOX USB CONNECTION USB/ETHERNET VIO WIRE W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
