MINI Cooper III (2013-2018) Headlights circuit, roadster

ADAPTIVE HEADLIGHT MODULE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/BRN/YEL WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE CAR ACCESS SYSTEM (LEFT TOP SIDE OF DASH) CENTER CONSOLE COMPUTER DATA LINES SYSTEM ELECTRONICS JUNCTION BOX FOOTWELL MODULE GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE HEADLAMP RANGE CONTROL HEADLAMP RANGE CONTROL POSITIONING MOTOR HIGH BEAM HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX LEFT HEADLIGHT LOW BEAM ORG/GRN WIRE PARKING BRAKE WARNING SWITCH RED WIRE RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE RIGHT HEADLIGHT SWIVELING MODULE W/ XENON HEADLIGHT W/O XENON HEADLIGHT WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE XENON HEADLIGHT BULB XENON LAMPS MODULE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BRN WIRE COOPER S W/ AERODYNAMICS PACKAGE FOG FRONT RIDE HEIGHT SENSOR GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE HEADLAMP RANGE CONTROL POSITIONING MOTOR HIGH BEAM HEADLIGHT RELAY LEFT HIGH BEAM HEADLIGHT LEFT REAR FOG LIGHT LEFT SIDE MARKER/FOG LIGHT LEFT TAILLIGHT LIGHTS/DIRECT INDICATOR/LOW BEAM STALK REAR FOG LIGHT REAR RIDE HEIGHT SENSOR RED WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RIGHT HEADLIGHT RIGHT HIGH BEAM HEADLIGHT RIGHT REAR FOG LIGHT RIGHT SIDE MARKER/ FOG LIGHT RIGHT TAIL LIGHT STEERING COLUMN SWITCH CLUSTER W/O AERODYNAMICS PACKAGE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE XENON HEADLIGHT BULB XENON LAMPS MODULE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE
