MINI Cooper III (2013-2018) windshield heated relay wiring diagram
This page shows the only wiring diagram for the component.windshield heated relay, which is found in the car MINI Cooper III (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
windshield heated relay wiring diagram (1 of 1)
ALTERNATOR
BATTERY
BLK WIRE
BLK/RED WIRE
BLOWER OUTPUT STAGE
DME MAIN RELAY
DYNAMIC STABILITY CONTROL (DSC)
ELECTRIC FAN CUTOUT RELAY
ELECTRIC FAN RELAY
ELECTRO- MECHANICAL POWER STEERING
FRONT ELECTRIC AUXILIARY HEATER
FRONT POWER DISTRIBUTION BOX
FUEL FILTER HEATING
FUSE 101
FUSE 103
FUSE 104
FUSE 31
FUSE 32
FUSE 34
FUSE 35
FUSE 37
FUSE 38
FUSE 39
FUSE 40
FUSE 400
FUSE 401
FUSE 402
FUSE 403
FUSE 404
FUSE 405
FUSE 406
FUSE 41
FUSE 42
FUSE 43
FUSE 45
FUSE 46
FUSE BOX
ID READER
IGNITION, FUEL INJECTION RELAY
INSTRUMENT CLUSTER CONTROL UNIT
INTEGRATED SUPPLY MODULE
INTELLIGENT BATTERY SENSOR
LEFT HEADLIGHT
NATURAL VACUUM LEAK DETECTION
NCA WIRE
PARKING BRAKE BUTTON
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
REMOTE CONTROL RECEIVER
RIGHT HEADLIGHT
ROOF FUNCTION CENTER
SIREN W/ TILT ALARM SENSOR
STARTER
TO BODY DOMAIN CONTROLLER (DIAGRAM 2 OF 4)
VALVETRONIC RELAY
WINDSHIELD HEATED RELAY
Go to component -> Power distribution circuit, hatchback (1 of 4) -> WINDSHIELD HEATED RELAY
