MINI Cooper III (2013-2018) w/ ulf-sbx interface box w/ ulf-sbx-h interface box high Wiring diagrams
This page contains all the electrical diagrams for the component. w/ ulf-sbx interface box w/ ulf-sbx-h interface box high, in which he is found in the car MINI Cooper III (2013-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ ulf-sbx interface box w/ ulf-sbx-h interface box high wiring diagram (1 of 3)
Go to component -> Most data bus circuit, convertible -> W/ ULF-SBX INTERFACE BOX W/ ULF-SBX-H INTERFACE BOX HIGH
w/ ulf-sbx interface box w/ ulf-sbx-h interface box high wiring diagram (2 of 3)
Go to component -> Most data bus circuit, coupe -> W/ ULF-SBX INTERFACE BOX W/ ULF-SBX-H INTERFACE BOX HIGH
w/ ulf-sbx interface box w/ ulf-sbx-h interface box high wiring diagram (3 of 3)
Go to component -> Most data bus circuit, roadster -> W/ ULF-SBX INTERFACE BOX W/ ULF-SBX-H INTERFACE BOX HIGH
