MINI Cooper III (2013-2018) sig temp Wiring diagrams

This page contains all the electrical diagrams for the component. sig temp, in which he is found in the car MINI Cooper III (2013-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

sig temp wiring diagram (1 of 3)

MINI Cooper III (2013-2018) sig temp wiring diagram (1 of 3)

ACTI SENS ACTI SERVO MOTOR ACTI VLV BLK WIRE BLU WIRE BRN WIRE CHARACTERISTIC MAP THERMOSTAT CRANKSHAFT SENSOR DME CONTROL UNIT ENG TEMP SENS ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL PRESSURE SENSOR EXHAUST CAMSHAFT SENSOR EXHAUST VANOS SOLENOID VALVE FUEL TANK VENT VALVE GND ACTUATOR GND METER GND SENS GND SERVO MOTOR GRN WIRE HOT FILM AIR MASS METER INTAKE AIR TEMPERATURE/ BOOST PRESSURE SENSOR INTAKE CAMSHAFT SENSOR INTAKE PIPE PRESSURE SENSOR INTAKE VANOS SOLENOID VALVE KNOCK SENSOR NCA WIRE OIL PRESSURE REGULATING VALVE ORG/ WIRE PLUG IN JUMPER SIG ACTUATOR SIG PUMP SIG SENS SIG TEMP SIG THERMOSTAT SIG VLV SPLY ACTUATOR SPLY SENS TERM 15 TERM 87 TERMINAL 15 SPLY THRUST AIR CONTROL VALVE TURBOCHARGER COOLANT PUMP VIO WIRE VOLUME CONTROL VALVE WASTEGATE VALVE WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo, convertible (4 of 4) -> SIG TEMP

sig temp wiring diagram (2 of 3)

MINI Cooper III (2013-2018) sig temp wiring diagram (2 of 3)

ACTI SENS ACTI SERVO MOTOR ACTI VLV BLK WIRE BLU WIRE BRN WIRE CHARACTERISTIC MAP THERMOSTAT CRANKSHAFT SENSOR DME CONTROL UNIT ENG TEMP SENS ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL PRESSURE SENSOR EXHAUST CAMSHAFT SENSOR EXHAUST VANOS SOLENOID VALVE FUEL TANK VENT VALVE GND ACTUATOR GND METER GND SENS GND SERVO MOTOR GRN WIRE HOT FILM AIR MASS METER INTAKE AIR TEMPERATURE/ BOOST PRESSURE SENSOR INTAKE CAMSHAFT SENSOR INTAKE PIPE PRESSURE SENSOR INTAKE VANOS SOLENOID VALVE KNOCK SENSOR NCA WIRE OIL PRESSURE REGULATING VALVE ORG/ WIRE PLUG IN JUMPER SIG ACTUATOR SIG PUMP SIG SENS SIG TEMP SIG THERMOSTAT SIG VLV SPLY ACTUATOR SPLY SENS TERM 15 TERM 87 TERMINAL 15 SPLY THRUST AIR CONTROL VALVE TURBOCHARGER COOLANT PUMP VIO WIRE VOLUME CONTROL VALVE WASTEGATE VALVE WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo, coupe (4 of 4) -> SIG TEMP

sig temp wiring diagram (3 of 3)

MINI Cooper III (2013-2018) sig temp wiring diagram (3 of 3)

ACTI SENS ACTI SERVO MOTOR ACTI VLV BLK WIRE BLU WIRE BRN WIRE CHARACTERISTIC MAP THERMOSTAT CRANKSHAFT SENSOR DME CONTROL UNIT ENG TEMP SENS ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL PRESSURE SENSOR EXHAUST CAMSHAFT SENSOR EXHAUST VANOS SOLENOID VALVE FUEL TANK VENT VALVE GND ACTUATOR GND METER GND SENS GND SERVO MOTOR GRN WIRE HOT FILM AIR MASS METER INTAKE AIR TEMPERATURE/ BOOST PRESSURE SENSOR INTAKE CAMSHAFT SENSOR INTAKE PIPE PRESSURE SENSOR INTAKE VANOS SOLENOID VALVE KNOCK SENSOR NCA WIRE OIL PRESSURE REGULATING VALVE ORG/ WIRE PLUG IN JUMPER SIG ACTUATOR SIG PUMP SIG SENS SIG TEMP SIG THERMOSTAT SIG VLV SPLY ACTUATOR SPLY SENS TERM 15 TERM 87 TERMINAL 15 SPLY THRUST AIR CONTROL VALVE TURBOCHARGER COOLANT PUMP VIO WIRE VOLUME CONTROL VALVE WASTEGATE VALVE WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo, roadster (4 of 4) -> SIG TEMP
