MINI Cooper III (2013-2018) interior light third row of seat wiring diagram
This page shows the only wiring diagram for the component.interior light third row of seat, which is found in the car MINI Cooper III (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
interior light third row of seat wiring diagram (1 of 1)
ACTIVE SOUND DESIGN
BLU WIRE
BLU/RED WIRE
BRN WIRE
CONTROLLER
ELECTROCHROMIC INTERIOR REARVIEW MIRROR
FRONT INTERIOR LIGHT
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
HIFI AMPLIFIER
INTERIOR LIGHT THIRD ROW OF SEAT
LEFT HEADLIGHT
LONGITUDINAL TORQUE DISTRIBUTION
NCA WIRE
RAIN/ LIGHT/ SOLAR/ CONDENSATION SENSOR
RED WIRE
REVERSING CAMERA
RIGHT HEADLIGHT
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> High/low bus circuit, hatchback (3 of 4) -> INTERIOR LIGHT THIRD ROW OF SEAT
