MINI Cooper III (2013-2018) gnd elct sens Wiring diagrams

This page contains all the electrical diagrams for the component. gnd elct sens, in which he is found in the car MINI Cooper III (2013-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

gnd elct sens wiring diagram (1 of 3)

MINI Cooper III (2013-2018) gnd elct sens wiring diagram (1 of 3)

ACT OIL PR CTRL ACT SOL VLVE EXH ACT SOL VLVE INT BLK WIRE BLU WIRE BRN WIRE CRANKSHAFT SENS CRANKSHAFT SENSOR DME CONTROL UNIT ECCENTRIC SHAFT SENSOR ELCT VLVE ACTUTOR ENGINE COOLANT TEMPERATURE SENSOR GND ELCT SENS GND INT SENS GRN WIRE GRY WIRE HOT-FILM AIR MAS INT SPLY SENS INTAKE CAMSHAFT SENSOR NCA WIRE ORG/ WIRE OXYGEN SENSOR BEFORE CATALYTIC CONVERTER OXYGEN SENSOR BEHIND CATALYTIC CONVERTER SHFT SENS SIG EXH SENS SIG FUL INJ SIG IG COIL SIG INT SENS VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/GRN WIRE

Go to component -> Wiring diagram engine performance 1.6l, convertible (3 of 4) -> GND ELCT SENS

gnd elct sens wiring diagram (2 of 3)

MINI Cooper III (2013-2018) gnd elct sens wiring diagram (2 of 3)

ACT OIL PR CTRL ACT SOL VLVE EXH ACT SOL VLVE INT BLK WIRE BLU WIRE BRN WIRE CRANKSHAFT SENS CRANKSHAFT SENSOR DME CONTROL UNIT ECCENTRIC SHAFT SENSOR ELCT VLVE ACTUTOR ENGINE COOLANT TEMPERATURE SENSOR GND ELCT SENS GND INT SENS GRN WIRE GRY WIRE HOT-FILM AIR MAS INT SPLY SENS INTAKE CAMSHAFT SENSOR NCA WIRE ORG/ WIRE OXYGEN SENSOR BEFORE CATALYTIC CONVERTER OXYGEN SENSOR BEHIND CATALYTIC CONVERTER SHFT SENS SIG EXH SENS SIG FUL INJ SIG IG COIL SIG INT SENS VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/GRN WIRE

Go to component -> Wiring diagram engine performance 1.6l, coupe (3 of 4) -> GND ELCT SENS

gnd elct sens wiring diagram (3 of 3)

MINI Cooper III (2013-2018) gnd elct sens wiring diagram (3 of 3)

ACT OIL PR CTRL ACT SOL VLVE EXH ACT SOL VLVE INT BLK WIRE BLU WIRE BRN WIRE CRANKSHAFT SENS CRANKSHAFT SENSOR DME CONTROL UNIT ECCENTRIC SHAFT SENSOR ELCT VLVE ACTUTOR ENGINE COOLANT TEMPERATURE SENSOR GND ELCT SENS GND INT SENS GRN WIRE GRY WIRE HOT-FILM AIR MAS INT SPLY SENS INTAKE CAMSHAFT SENSOR NCA WIRE ORG/ WIRE OXYGEN SENSOR BEFORE CATALYTIC CONVERTER OXYGEN SENSOR BEHIND CATALYTIC CONVERTER SHFT SENS SIG EXH SENS SIG FUL INJ SIG IG COIL SIG INT SENS VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/GRN WIRE

Go to component -> Wiring diagram engine performance 1.6l, roadster (3 of 4) -> GND ELCT SENS
