MINI Cooper III (2013-2018) front power distribution box wiring diagram
This page shows the only wiring diagram for the component.front power distribution box, which is found in the car MINI Cooper III (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front power distribution box wiring diagram (111 of 111)
1-TIER
2-TIER
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CHARACTERISTIC MAP THERMOSTAT
COMPUTER DATA LINES SYSTEM
COOLANT PRESSURE SENSOR
DME CONTROL UNIT
ELECTRIC FAN
ELECTRIC FAN RELAY
ELECTRIC FAN RELAY 2
ENGINE CONTROLS SYSTEM
ENGINE TEMPERATURE SENSOR
FRONT POWER DISTRIBUTION BOX
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ DME RELAY ENERGIZED
ORG/ WIRE
RED WIRE
RED/BLU WIRE
W/ AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> 1.6l turbo, cooling fan circuit -> FRONT POWER DISTRIBUTION BOX
