MINI Cooper III (2013-2018) front passenger's seat surface heating wiring diagram
This page shows the only wiring diagram for the component.front passenger's seat surface heating, which is found in the car MINI Cooper III (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front passenger's seat surface heating wiring diagram (1 of 1)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT SURFACE HEATING
FRONT PASSENGER'S SEAT BACKREST HEATING
FRONT PASSENGER'S SEAT HEATING ELECTRONICS
FRONT PASSENGER'S SEAT SURFACE HEATING
FRONT POWER DISTRIBUTION BOX
FUSE 127
FUSE 128
GRN/VIO WIRE
GRY WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT W/
RED/GRN WIRE
RELAY ENERGIZED
VIO WIRE
WHT WIRE
Go to component -> Power seats circuit, hatchback -> FRONT PASSENGER'S SEAT SURFACE HEATING
