MINI Cooper III (2013-2018) electronics of touch detection wiring diagram
This page shows the only wiring diagram for the component.electronics of touch detection, which is found in the car MINI Cooper III (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
electronics of touch detection wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS
DRIVER ASSISTANCE SYSTEM OPERATING FACILITY W/ HAZARD WARNING SWITCH
DYNAMIC STABILITY CONTROL (DSC)
ELECTRIC STEERING LOCK
ELECTROMECHANICAL POWER STEERING
ELECTRONIC STEERING WHEEL MODULE
ELECTRONICS OF TOUCH DETECTION
FRONT POWER DISTRIBUTION BOX
FUSE 35
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HEATING, AIR CONDITION SYSTEM
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL UNIT
LIGHT OPERATING UNIT
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/RED WIRE
RED WIRE
RED/WHT WIRE
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK
STEERING COLUMN SWITCH CLUSTER
TELEMATICS COMMUNICATION BOX
VIO WIRE
VIO/YEL WIRE
W/ TELEMATICS COMMUNICATION BOX
W/O TELEMATICS COMMUNICATION BOX
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> High/low bus circuit, hatchback (1 of 4) -> ELECTRONICS OF TOUCH DETECTION
