MINI Cooper III (2013-2018) driver belt force limiter alternator Wiring diagrams

This page contains all the electrical diagrams for the component. driver belt force limiter alternator, in which he is found in the car MINI Cooper III (2013-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

driver belt force limiter alternator wiring diagram (1 of 3)

BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CENTER CONSOLE CONVERTIBLE COUPE, ROADSTER CLUBMAN DEACTIVATE IND DRIVER BELT FORCE LIMITER ALTERNATOR DRIVER SIDE AIR BAG INFLATOR ASSEMBLY DRIVER'S SEAT BELT TENSIONER GENERATOR DRIVER'S SIDE DOOR AIR BAG SENSOR DRIVER'S SIDE FRONT AIR BAG SENSOR DRIVER'S SIDE HEAD AIR BAG INFLATOR ASSEMBLY DRIVER'S SIDE SEAT BELT RETRACTOR TENSIONER DRVR ALT - DRVR SEAT BELT DRVR SEAT SENS DRVR SIDE - FRONT PASSENGER BELT FORCE LIMITER ALTERNATOR FRONT PASSENGER'S SIDE DOOR AIR BAG SENSOR FRT PASS SENS GRN WIRE GROUND GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE L B-PILLAR SENS LEFT HEAD - LF DOOR SENS LF SENS MULTIPLE RESTRAINT SYSTEM CONTROL UNIT NCA WIRE OCCUPANCY SIG PASS ALT + PASS SEAT BELT PASS SIDE + PASSENGER SIDE AIR BAG INFLATOR ASSEMBLY PASSENGER'S SEAT BELT TENSIONER GENERATOR PASSENGER'S SIDE B-PILLAR AIR BAG SENSOR PASSENGER'S SIDE FRONT AIR BAG SENSOR PASSENGER'S SIDE HEAD AIR BAG INFLATOR ASSEMBLY PASSENGER'S SIDE SEAT BELT RETRACTOR TENSIONER R B-PILLAR SENS RED WIRE RF DOOR SENS RF SENS RIGHT HEAD + TERMINAL R VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit, convertible (1 of 2) -> DRIVER BELT FORCE LIMITER ALTERNATOR
