MINI Cooper III (2013-2018) brn wiring diagrams

brn wiring diagram (151 of 296)

ACTIVE SOUND DESIGN AUXILIARY BRAKE LIGHT BASE PLATE BODY DOMAIN CONTROLLER BOOT LID/ TAILGATE LOCK BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE CENTER REAR SEAT BELT BUCKLE CONTACT CENTRAL INSTRUMENT CRASH SAFETY MODULE DRIVER SEAT POSITION SENSOR DRIVER'S SEAT BELT BUCKLE CONTACT DYNAMIC STABILITY CONTROL (DSC) ELECTRIC FAN ELECTRICAL EXHAUST FLAP ELECTROMECHANICAL POWER STEERING EXTERIOR BOOT LID BUTTON FRONT ELECTRIC AUXILIARY HEATER FRONT INTERIOR LIGHT FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER SEAT OCCUPANCY DETECTION FRONT PASSENGER SEAT POSITION SENSOR FUEL PUMP CONTROL MODULE GEAR INDICATOR LIGHT HEAD UNIT HEATED WINDSCREEN HEATED WINDSCREEN RELAY HIFI AMPLIFIER ID READER LEFT LICENSE PLATE LIGHT LEFT OUTER TAIL LIGHT LEFT REAR SEAT BELT BUCKLE CONTACT LEFT REAR SIDE MARKER LIGHT NATURAL VACUUM LEAK DETECTION NCA WIRE OPTIONAL EQUIPMENT SYSTEM PASSENGER SEAT BELT BUCKLE CONTACT REAR FOG LIGHT 1 REAR FOG LIGHT 2 REAR INTERIOR LIGHT REAR WINDOW DEFOGGER REAR WIPER REMOTE CONTROL RECEIVER REVERSING CAMERA RIGHT FRONT FOOTWELL LIGHT RIGHT LICENSE PLATE LIGHT RIGHT OUTER TAIL LIGHT RIGHT REAR SEAT BELT BUCKLE CONTACT RIGHT REAR SIDE MARKER LIGHT SELECTOR LEVER TELEMATICS COMMUNICATION BOX TRAILER MODULE TRAILER SOCKET

Go to component -> Ground distribution circuit, hatchback (3 of 3) -> BRN WIRE

brn wiring diagram (152 of 296)

BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE CCC/M-ASK CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM EXCEPT CONVERTIBLE GPS ANTENNA GRN WIRE GRY WIRE GRY/RED WIRE LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER M-ASK FAN MISSION CONTROL MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RIGHT REAR WOOFER ROOF ANTENNA WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, convertible w/ ccc/m-ask (1 of 2) -> BRN WIRE

brn wiring diagram (153 of 296)

ANTENNA AMPLIFIER ANTENNA DIVERSITY AUX-IN CONNECTION BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DC/DC CONVERTER DIVERSITY ANTENNA CIRCUIT FRONT POWER DISTRIBUTION BOX GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL JBE HIGH W/ MSA JBE LOW OR HIGH JUNCTION BOX LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER LEFT REAR WOOFER MINI JOYSTICK MISSION CONTROL MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE RADIO REAR ANTENNA (ROADSTER) ROOF ANTENNA (COUPE) (COUPE: CENTER REAR OF ROOF) RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR WOOFER ROD AERIAL ANTENNA VIO WIRE VOICE CONTROL MICROPHONE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, coupe w/o ccc/m-ask & amplifier -> BRN WIRE

brn wiring diagram (154 of 296)

BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT DVD CHANGER GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT MICROPHONE MICROPHONE 2 (RIGHT FRONT OF ROOF) MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, hatchback w/ base radio & active sound design (2 of 4) -> BRN WIRE

brn wiring diagram (155 of 296)

BASE PLATE FAN BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/GRN WIRE CENTER FRONT MID-RANGE SPEAKER CENTRAL INSTRUMENT DVD CHANGER FRONT CENTER TWEETER FRONT POWER DISTRIBUTION BOX FUSE 80 FUSE 91 GRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT W/ LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER MOST DATA BUS CIRCUIT NCA WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RELAY 1 ENERGIZED RIGHT FRONT WOOFER VIO WIRE VIO/GRY WIRE VIO/WHT WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

Go to component -> Radio circuit, hatchback w/ hifi radio & active sound design (3 of 5) -> BRN WIRE

brn wiring diagram (156 of 296)

ANTENNA DIVERSITY AUX-IN CONNECTION BASE PLATE BLK WIRE BLU WIRE BRN WIRE CAR SHARING MODULE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE HEAD UNIT HEAD UNIT BASIS ID READER MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/YEL WIRE ROOF ANTENNA TELEMATICS COMMUNICATION BOX USB CONNECTION USB/ETHERNET VIO WIRE W/ NAVIGATION W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, hatchback w/ hifi radio & active sound design (5 of 5) -> BRN WIRE

brn wiring diagram (157 of 296)

BLK WIRE BLU WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE BRN/RED WIRE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 FUSE 87 GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT HEAD UNIT BASIS HOT W/ TERMINAL MICROPHONE MICROPHONE 2 (RIGHT FRONT OF ROOF) NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE REVERSING CAMERA ROOF ANTENNA USB/ETHERNET VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ NAVIGATION W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, hatchback w/ hifi radio w/o active sound design (1 of 4) -> BRN WIRE

brn wiring diagram (158 of 296)

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTER FRONT MID-RANGE SPEAKER CENTER FRONT TWEETER CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT DVD CHANGER GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT WOOFER VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, hatchback w/ hifi radio w/o active sound design (2 of 4) -> BRN WIRE

brn wiring diagram (159 of 296)

ANTENNA DIVERSITY AUX-IN CONNECTION BASE PLATE BLK WIRE BLU WIRE BRN WIRE CAR SHARING MODULE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE HEAD UNIT HEAD UNIT BASIS ID READER MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/YEL WIRE ROOF ANTENNA TELEMATICS COMMUNICATION BOX USB CONNECTION USB/ETHERNET VIO WIRE W/ NAVIGATION W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, hatchback w/ hifi radio w/o active sound design (4 of 4) -> BRN WIRE

brn wiring diagram (160 of 296)

ANTENNA AMPLIFIER ANTENNA DIVERSITY AUX-IN CONNECTION BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DC/DC CONVERTER DIVERSITY ANTENNA CIRCUIT FRONT POWER DISTRIBUTION BOX GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL JBE HIGH W/ MSA JBE LOW OR HIGH JUNCTION BOX LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER LEFT REAR WOOFER MINI JOYSTICK MISSION CONTROL MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE RADIO REAR ANTENNA (ROADSTER) ROOF ANTENNA (COUPE) (COUPE: CENTER REAR OF ROOF) RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR WOOFER ROD AERIAL ANTENNA VIO WIRE VOICE CONTROL MICROPHONE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Radio circuit, roadster w/o ccc/m-ask & amplifier -> BRN WIRE
