Tire pressure monitoring circuit, base for MINI Cooper II facelift (2010-2015)
Tire pressure monitoring circuit, base
BLK/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISTRIBUTION BOX (RIGHT KICK PANEL)
EXCEPT CONVERTIBLE
FUSE 19
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT ELECTRONIC WHEEL MODULE
LEFT REAR ELECTRONIC WHEEL MODULE
ORG/GRN WIRE
RIGHT FRONT ELECTRONIC WHEEL MODULE
RIGHT REAR ELECTRONIC WHEEL MODULE
TIRE PRESSURE CONTROL (RDC)
