MINI Cooper II facelift (2010-2015) 1.6l, cooling fan circuit

1.6L TURBO 1.6L BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE CHARACTERISTIC MAP THERMOSTAT CHARACTERISTIC MAP THERMOSTAT (RIGHT REAR SIDE OF ENGINE) COMPUTER DATA LINES SYSTEM COOLANT PRESSURE SENSOR DME CONTROL UNIT DME CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) ELECTRIC FAN ELECTRIC FAN (LEFT FRONT OF ENGINE COMPT) ELECTRIC FAN RELAY ENGINE CONTROLS SYSTEM ENGINE TEMPERATURE SENSOR FRONT POWER DISTRIBUTION BOX FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE GRY/RED WIRE HOT AT ALL TIMES HOT W/ DME RELAY ENERGIZED ORG/ WIRE RED/BLU WIRE VIO/WHT WIRE W/ AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE
