MINI Cooper II facelift (2010-2015) w/o light package w/ light package Wiring diagrams
This page contains all the electrical diagrams for the component. w/o light package w/ light package, in which he is found in the car MINI Cooper II facelift (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o light package w/ light package (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DRIVER'S DOOR ENTRANCE LIGHT
FUSE
GLOVE COMPARTMENT LIGHT
JUNCTION BOX (RIGHT KICK PANEL)
LEFT FRONT MAKE- UP MIRROR LIGHT
LUGGAGE COMPARTMENT LIGHT
PASSENGER'S DOOR ENTRANCE LIGHT
REAR FRONT INTERIOR DRIVER'S LIGHT SIDE ENTRY LAMP (COUNTRYMAN)
REAR PASSENGER'S SIDE ENTRY LAMP (COUNTRYMAN)
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT MAKE- UP MIRROR LIGHT
TRUNK LID CENTRAL LOCKING DRIVE (CENTER REAR OF TRUNK)
VIO/GRY WIRE
VIO/YEL WIRE
W/ W/O LIGHT PACKAGE LIGHT PACKAGE
W/O LIGHT PACKAGE W/ LIGHT PACKAGE
YEL WIRE
Go to component -> Courtesy lamps circuit, countryman with interior lights package (3 of 3) -> W/O LIGHT PACKAGE W/ LIGHT PACKAGE
Wiring diagram w/o light package w/ light package (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DRIVER'S DOOR ENTRANCE LIGHT
FUSE
GLOVE COMPARTMENT LIGHT
JUNCTION BOX (RIGHT KICK PANEL)
LEFT FRONT MAKE- UP MIRROR LIGHT
LUGGAGE COMPARTMENT LIGHT
PASSENGER'S DOOR ENTRANCE LIGHT
REAR FRONT INTERIOR DRIVER'S LIGHT SIDE ENTRY LAMP (COUNTRYMAN)
REAR PASSENGER'S SIDE ENTRY LAMP (COUNTRYMAN)
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT MAKE- UP MIRROR LIGHT
TRUNK LID CENTRAL LOCKING DRIVE (CENTER REAR OF TRUNK)
VIO/GRY WIRE
VIO/YEL WIRE
W/ W/O LIGHT PACKAGE LIGHT PACKAGE
W/O LIGHT PACKAGE W/ LIGHT PACKAGE
YEL WIRE
Go to component -> Courtesy lamps circuit, paceman with interior lights package (3 of 3) -> W/O LIGHT PACKAGE W/ LIGHT PACKAGE
