MINI Cooper II facelift (2010-2015) w/o aerodynamics package Wiring diagrams
This page contains all the electrical diagrams for the component. w/o aerodynamics package, in which he is found in the car MINI Cooper II facelift (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/o aerodynamics package wiring diagram (1 of 2)
A/T
BLU WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
CLUBMAN, COUPE, CONVERTIBLE W/O AERODYNAMICS PACKAGE OR COOPER S COUNTRYMAN
COMPUTER DATA LINES SYSTEM
FOOTWELL MODULE
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
JUNCTION BOX
JUNCTION BOX (RIGHT KICK PANEL)
LEFT TAILLIGHT
ORG/GRN WIRE
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
REVERSE
REVERSING LIGHT
REVERSING LIGHT SWITCH
REVERSING LIGHT SWITCH (M/T) (ON TRANSMISSION)
RIGHT TAILLIGHT
TRANSMISSION CONTROL
TRANSMISSION CONTROL (A/T) (UNDER LEFT SIDE OF DASH)
TRANSMISSION CONTROL UNIT
TRANSMISSION SHIFT DEVICE
VIO/BLK WIRE
W/O AERODYNAMICS PACKAGE
WHT/BLK WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Backup lamps circuit -> W/O AERODYNAMICS PACKAGE
