MINI Cooper II facelift (2010-2015) wht Wiring diagram
This page shows the only wiring diagram for the component.wht, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wht (101 of 101)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
CRANKCASE VENTILATION PLUG-IN JUMPER
DME CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
ENGINE VENTILATION HEATING
FRICTION WHEEL DRIVE
FUEL INJECTION 1
FUEL INJECTION 2
FUEL INJECTION 3
FUEL INJECTION 4
GND ACTUATOR
GND FRICTION
GND PUMP
GND SENS
GND VLVTRONIC
GRN WIRE
GRY WIRE
IGN COIL 1 SIG
IGN COIL 2 SIG
IGN COIL 3 SIG
IGN COIL 4 SIG
INJ 1 SIG
INJ 2 SIG
INJ 3 SIG
INJ 4 SIG
NCA WIRE
ORG/ WIRE
OXYGEN SENSOR AFTER CATALYTIC CONVERTER
OXYGEN SENSOR BEFORE CATALYTIC CONVERTER
RAIL PRESSURE SENSOR
RED/GRN WIRE
SIG METER
SIG MOTOR
SIG OIL PRESS
SIG SENS
SIG VLV
SIG VLVTRONIC
SPLY MOTOR
SPLY SENS
TERM 15 SPLY
VIO WIRE
VLV ACTI
VOLUME CONTROL VALVE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo, except jcw (3 of 4) -> WHT WIRE
