MINI Cooper II facelift (2010-2015) vol suply Wiring diagram
This page shows the only wiring diagram for the component.vol suply, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vol suply (1 of 1)
AIR CTRL VLVE
BLK WIRE
BLU WIRE
CHARACTERISTIC MAP THERMOSTAT
COOLANT PUMP
CTRL VLVE
DME CONTROL UNIT
ELCT THROTTLE VLVE
ENG TEMP SENS
ENGINE COOLANT TEMPERATURE SENSOR
FUEL TANK VENT VALVE
GRN WIRE
HOT FILM AIR MASS METER
INT AIR TEMP
INT PR SENS
INT SENS
INT TEMP PR SENS
INT VENT VLVE
INTAKE CAMSHAFT SENSOR
INTAKE PIPE PRESSURE SENSOR
INTAKE TEMPERATURE BOOST PRESSURE SENSOR
INTAKE VANOS SOLENOID VALVE
KNOCK SENS
KNOCK SENSOR
MAS METR
NCA WIRE
ORG/ WIRE
OXYGEN SENS
OXYGEN SENS HEATE
PIPE PR SENS
PIPE PR SENS INT
SENS
SENS GND
SIG MAP
SUPLY INT TEMP
TERM 87
THROTTLE VLVE
THRUST AIR CONTROL VALVE
TURBOCHARGER COOLANT PUMP
VIO WIRE
VOL SUPLY
VOLUME CONTROL VALVE
WASTEGATE VALVE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo, jcw (4 of 4) -> VOL SUPLY
